Brother PT-P950NW Commercial Wireless Network Labeling System

SKU:
PTP950NW
MSRP:
$499.95
Price:
$435.99
Always FREE Shipping!
Ships Same Day by 3:30 EST
1 Year Replacement Warranty!


Label More - Pay Less!
1 Year Replacement Warranty!
Ships Quickly - Speedy Delivery!

Product Description

NEW! The PT-P950NW is a complete wireless on-demand network laminating label printing solution that comes with printer, accessories, label design and print software, and a full length UL certified tape – all this for the price of just the printer! This small footprint printer produces wide, premium quality laminated labels at 360dpi print resolution, up to 32mm print height on 36mm tape, and features a built-in automatic cutter that trims a continuous "tape" to virtually any length, one at a time or as a strip of pre-cut labels. Brother laminated labels can withstand abrasion, fading, extreme temperatures, chemicals and moisture.

Replaces Brother's PT9800PCN

View Product Brochure

MAIN FEATURES:

  • Wi-Fi, Ethernet, USB, Host USB, Serial & Optional Bluetooth (PA-BI-002) Interfaces - Versatile Wireless and Wired Connectivity Options
  • Produce Premium Quality, UL Certified¹ Laminated Labels On-Demand - Virtually Eliminates the Need to Purchase Pre-Printed Labels From a Converter for Custom and Short Run Labels
  • Infrastructure, Adhoc and Direct Wireless Wi-Fi Communications - Connect Directly to a Windows Computer, iOS and Android Smartphone or Tablet
  • Larger Print Head Prints up to 32mm High on 36mm Wide Tape at 360 dpi Printing Resolution - Prints Larger, Easy to Read Labels with Smooth Curves that Help Eliminate Jagged and Pixilated Images, Including Very Small Characters and Graphics
  • Automatic Dual Blade Cutting Mechanism - Pre-Print Strip of Easy to Peel labels as an Alternative to Sheets and Rolls of Die Cut Labels
  • Future Proof Optional Accessories: Li-ion Rechargeable Battery (PA-BT-4000LI), Battery Base (PA-BB-002), Touch Panel & Display (PA-TDU-003) and Bluetooth v2.1 (PA-BI-002) - Make Printer Configuration Purchasing Decision on Current Requirements, Optional Accessories are User Installable After Deployment
  • Printer Includes AC Adapter and Easy to Use, Advanced Label Design Software, UL Certified Tape and Cables - Comes With Everything you Need to Help you Design and Print Premium Quality Laminated Labels
  • Prints Laminated Labels up to 3.1 ips - Print Speed is up to 4x Faster Than Other Brother Models and is Ideal for Work in Progress (WIP) and Higher Volume Labeling Applications
  • Template Mode Printing and Downloadable Databases, Optional Touch Panel & Display (PA-TDU-003) - Easy to Develop Solutions to Print Standalone, From Scanning a Barcode or Connected to an Industrial Device (ex: PLC or Tester)
  • Uses HGe/TZe/HSe Tape - All in One, Drop in Cartridge Design Helps Ensure you Get the Best Print Quality and Makes Replacing Media Virtually Trouble Free
  • Small Footprint, only 4.7" wide x 5.7" high x 7.6" deep - Ideal for Use on Crowded Bench Tops, Limited Work Space and Even on Carts
  • 2 Year "At your side" Limited Warranty - Helps Assure Operational Confidence and Reliability, and Helps Minimize Down Time




Other Details

Model Type:
Industrial Powered Desktop Label Printer
TYPE:
Desktop
TAPE FAMILY:
TZe Series
TAPE FAMILY:
HGe Series
Tape Sizes:
1/4", 3/8", 1/2", 3/4", 1", 1.5"
Tape Technology:
TZe: up to 1-1/2"
Tape Types:
High Grade, Standard & Extra-Strength Adhesive, Flexible ID, Heat Shrink Tube, Tamper-Evident, Iron-On Fabric, Acid Free, Non-Laminated
LCD Display:
Optional Touch Panel Display (PA-TDU-003)
Backlight:
Optional Touch Panel & Display (PA-TDU-003)
Maximum Print Resolution:
360 x 720 dpi (14 x 28 dots/mm)
Maximum Print Speed:
HGe/TZe Tape: Up to 3.15 ips (80 mm/sec)
Batteries:
Optional Li-ion Rechargeable Battery (PA-BT-4000LI), Requires Optional Battery Base (PA-BB-002)
Keyboard:
Optional Touch Panel Display (PA-TDU-003)
Cutter:
Automatic (Built-In) Cutter: Full-Cut mode and Crack and Peel mode
Operation Mode:
Computer Connected (GDI Printer, Template), Connected to Host Peripheral (USB or Serial)
Printer Emulation:
Raster, ESC P, Text (Template/Form Mode)
ENERGY STAR® certified:
Yes
Control Panel:
On/Off, Feed/Cut, Wi-Fi On/Off
Power Switch:
Digital
Power Supply:
120-240VAC 60/50 Hz
AC Adapter:
AD-9100ESA (Included)
Interface:
Wi-Fi WLAN (802.11b/g/n), LAN (10/100 Base-TX), USB 2.0, Host USB, Serial (RS-232C), Optional Bluetooth v2.1 (PA-BI-002)
Near Field Communication:
None
Mobile Device Printing App:
Mobile Cable Label Tool, Mobile Transfer Express
Mobile Device Compatibility:
iOS 3.0 or Later, Android 1.6 or Later
----------------:
---------------
Microsoft Word/Outlook/Excel Add-ins:
Office 2000/2003/2007
Auto Power Off:
Yes, Programmable
Fonts:
Resident: Helsinki, Letter Gothic; P-touch Editor Software: Brother & Compatible TrueType Fonts
Font Sizes:
Scalable Fonts
Built-in Symbols:
None
Font Styles:
Regular, Bold, Shadow, Outline, Horizontal Lines, Surround, Invert
Max. Print Height:
1.26" (32 mm)
Multi-Block:
Yes
Label Length Setting:
0.16" - 39.37" (4.06mm - 999.99mm)
Auto Incrementation:
Alpha Numeric
Auto Numbering:
Alpha Numeric
Horizontal Alignment:
Left, Center, Right Justification
Vertical Printing:
Yes
Mirror Printing:
Yes
Rotate Printing:
Yes
Text Insert:
Yes
Text Framing/Fill Pattern:
Yes
Multi-copy Print:
Up to 5,000 Copies
Memory:
6MB
Memory for Transferred Data (Number):
Up to 99 Template Files
Favorites Function Key:
Optional Touch Panel & Display (PA-TDU-003)
Date/Time Stamp:
Yes
Snapper function:
Yes
Download data to unit:
Yes
Built-in Designs/Templates:
Downloadable
Download templates from Brother Cloud:
No
Database Printing:
Yes
Database File Compatibility:
*.accdb, *.mdb, *.xlsx, *.xlsm, *.xls, *.csv, *.txt, and Microsoft MSDE/SQL Server
Internal Fonts:
ESC P: Helsinki, Letter Gothic Template (Bitmap & Outline): Helsinki, Brussels, Letter Gothic
Internal Font Sizes:
ESC P: 21, 28, 44, 56, 88, 120 dots Template (Bitmap): 21, 28 dots Template (Outline): 35 - 380 dots (20 sizes)
Internal Font Styles:
ESC P: Bold, Italic, Underline Template: Bold, Italic, Vertical, Outline, Shadow, Outline/Shadow
Barcoding:
Yes
Barcodes (Stand-alone mode):
Linear: Code39, Code128, ITF, UPC-A/E, EAN-8/13, GS1-128 [UCC/EAN-128], Codabar (NW-7); 2D: PDF417/Micro PDF417, Data Matrix, Maxicode, QR Code/Micro QR Code
Barcodes (connected to computer):
P-touch Editor Software - Linear: Code39, Code128, ITF, UPC-A/E, EAN-8/13, GS1-128 (UCC/EAN-128), Codabar (NW-7), ISBN-2/5, POSTNET, Laser, GS1 DataBar (RSS); 2D: PDF417, QR/Micro QR Code, Data Matrix, MaxiCode, GS-1 Composite, AztecCodeC/EAN128, Pos
(PC) / (MAC) Connectivity:
Wi-Fi WLAN (802.11b/g/n), USB 2.0
Operating System:
Windows Server 2012 R2/2012/2008 R2/2008; Windows 10/8/7 (32/64bit), Windows Vista (32/64bit) Mac OS X 10.10x - 10.8x, iOS 3.0 or Later, Android 1.6 or Later
(PC) / (MAC) Available hard disk space:
50 MB
(PC) Minimum RAM memory:
512 MB
(Mac) Minimum RAM memory:
128 MB
Included Items:
One 0.94" (24mm) x 26.2' (8m) Black on White Extra-Strength Adhesive Laminated "TZe" Tape (TZeS251), USB interface cable, P-touch Editor software and printer drivers (Online), AC Adapter/Power Cord, Quick Start Guide
Housing Dimensions:
4.7" (119.4mm) x 7.6" (193mm) x 5.7" (144.8mm)
Housing Weight:
3.3 lbs (1.5 kg)
Housing Color:
Black
Warranty:
2-Year Depot Warranty (Manufacturer)
UPC Code:
0-12502-64299-2
